Packaging unit

Piece

Detailed information

Sampler for all-layer samples of viscous, paste-like, semi-liquid substances, according to DIN 51750 pt. 3 and DIN EN ISO 15528. Different layers remain intact particularly with paste-like substances.

Typical application area of the product

Sampler for all-layer samples of viscous, paste-like, semi-liquid substances.
How to use the product

For viscous substances:

1. The valve lance is inserted all the way to the bottom, whilst being closed.
2. It is opened, closed and pulled out again.


For paste-like substances:

1. The valve lance is inserted all the way to the bottom, whilst being open.
2. It is closed and pulled out again.
zer12_v25_en_ex_vxa.pdf zer12_v25_en_ex_vxa.pdf
5359-1x00_klappstecher_gebrauchsanleitung.pdf 5359-1x00_klappstecher_gebrauchsanleitung.pdf
  • Valve lance

Specifications

General material

1.4404 (316L)
Stainless steel 1.4404, AISI 316L

Sample chamber details

Number of collection openings:
1 St
Sample quantity:
300 ml

Lance dimensions

Pipe Ø:
34 mm
Plunge depth:
500 mm
Total length:
583.5 mm
Outer Ø:
34 mm
To the list of chemical resistance
