StopCock angled
- Absolutely tight-closing
- Particularly smooth-running
- With connection union nut, guarantees vertical position of the tap
- Pressure-resistant up to 2 bar at 20 °C
- With outlet angle and swivelling drip preventer
- With reducing spout for narrow bottle openings, 6-8 mm outer diameter
- Pressure-resistant up to 2 bar at 20 °C (without outlet angle and spout)
Packaging unit
Piece
Please note
Not suitable for crystallising substances!
Detailed information
The swivelling spout angle prevents dripping. The reduced spout allows the water to flow into narrow openings.
The StopCock discharge cocks fit all containers with G 3/4" connection threads. Thread adapters facilitate connection of cocks to nearly all containers.
Typical application area of the product
The outlet tap is suitable for filling liquids from canisters and barrels.
- StopCock angled
Specifications
General material
PP
Polypropylene
General material
PE-HD
High-density polyethylene (HDPE)
General material
PE-LD
Low-density polyethylene (LDPE)
Further materials
PTFE
Polytetrafluoroethylene
Connection
- Connection type:
- Thread
- Thread:
- G 3/4 Zoll
- Version:
- Cap nut
Colouring
- Colour:
- blue
Spigot outlet
- Outer outlet Ø:
- 6 mm
- Outlet type:
- Angle discharge with spout
Nominal Ø
- Nominal diameter:
- 5 mm
Dimensions
- Length:
- 121 mm
- Width:
- 29 mm
- Height:
- 95 mm
