StopCock PA, electroconductive
- With discharge angle and rotatable spout preventing drips
- With tapered spout for bottles with narrow openings with a diameter from 6 to 8 mm
- Media-contacting parts PA conductive to electricity and PTFE
- Supplied with PA adapter conductive to electricity for 3/4" inner thread
- Tight-closing for complete seal
- Especially effortless
- With connecting cap nut, guaranteed vertical position of the cock
- Pressure-resistant up to 2 bar at 20 °C (without discharge bracket and grommet)
Packaging unit
Piece
Please note
Caution! When handling flammable, highly flammable liquids, the explosion protection guidelines must be observed. All parts must be earthed, use anti-static set!
Pay attention to the chemical resistance of the materials! See also List of chemical resistance
Detailed information
Commercially available spigots made of the materials polyethylene or polypropylene cannot be used for solvents.
StopCock PA fits onto 3/4" outer threads and with the supplied adapter onto 3/4" inner threads and therefore onto nearly all commercially available canisters and barrels where the discharge thread is at the bottom.
The StopCock discharge cocks fit all containers with G 3/4" connection threads. Thread adapters facilitate connection of cocks to nearly all containers.
Typical application area of the product
The spigot StopCock PA is made of electrically conductive polyamide and therefore perfectly suitable for solvents.
- StopCock PA, electroconductive
- Adapter onto 3/4" inner threads
Specifications
General material
PA
Polyamide
Further materials
PTFE
Polytetrafluoroethylene
Connection
- Connection type:
- Thread
- Thread:
- G 3/4 Zoll
- Version:
- Cap nut
Additional thread
- Thread:
- G 3/4 Zoll
- Version:
- External thread
Colouring
- Colour:
- black
Spigot outlet
- Outer outlet Ø:
- 6 mm
- Outlet type:
- Angle discharge with spout
Nominal Ø
- Nominal diameter:
- 5 mm
Dimensions
- Length:
- 150 mm
- Width:
- 33 mm
- Height:
- 95 mm
