Sampler Liquid CupSampler
Packaging unit
Piece
Detailed information
It is possible to carry out point sampling of liquids of varying viscosity with the stainless steel AISI 316L (1.4404) Liquid CupSampler. Media-containing particles can also be sampled without difficulty.
The sampler can be used in the fields of chemistry, foodstuffs and cosmetics.
The cup can be unscrewed from the stem, allowing easy cleaning.
Typical application area of the product
The sampler can be used in the fields of chemistry, foodstuffs and cosmetics.
- Sampler Liquid CupSampler
Specifications
General material
1.4404 (316L)
Stainless steel 1.4404, AISI 316L
Scoop dimensions
- Immersion depth max.:
- 950 mm
- Total length:
- 1060 mm
- Outer Ø:
- 55 mm
Contents of scoop container
- Contents:
- 100 ml
Other dimensions
- Collection container height:
- 60 mm
- Handle/handle length:
- 1000 mm
